Кухня Free 3D Furniture Projects and Blueprints from the Flatma Community

Interactive 3D model: rotate to inspect, open in designer to customize

This project is shared by the community and serves as a reference and starting point. Verify all dimensions and structural correctness before cutting

Open in Flatma

null

Overall material utilization factor - 35.59 %
Total edge banding length - 14.25′ (46.745 m)
Total cutting length - 42.25′ (138.617 m)

Materials	Hardware
Laminated Particle Board 0.63″x82.68″x110.24″ (16x2100x2800 mm) ( color W1000_9) - 1 pcs. + Edge banding 0.4 x 19 (W1000_9) - 3.64′ (11.95 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color W1000_9) - 1 pcs. + Edge banding 0.4 x 19 (W1000_9) - 1.58′ (5.174 m) Lower Guide A08 0.24″x2.4″x106.3″ (6x61x2700 mm) ( color U999_19) - 1 pcs. + Edge banding 1 x undefined (U999_19) - 0′ (0 m) Upper Guide A04 1.57″x3.23″x106.3″ (40x82x2700 mm) ( color U999_19) - 1 pcs. + Edge banding 1 x undefined (U999_19) - 0′ (0 m) Laminated Particle Board 0.63″x82.68″x110.24″ (16x2100x2800 mm) ( color U702_9) - 2 pcs. + Edge banding 0.4 x 19 (U702_9) - 2.97′ (9.732 m) Handle Profile A14 1.34″x1.02″x106.3″ (34x26x2700 mm) ( color U999_19) - 2 pcs. + Edge banding 1 x undefined (U999_19) - 0′ (0 m) Top Profile A02 0.87″x0.59″x106.3″ (22x15x2700 mm) ( color U999_19) - 1 pcs. + Edge banding 1 x undefined (U999_19) - 0′ (0 m) Bottom Profile A01 2.24″x0.59″x106.3″ (57x15x2700 mm) ( color U999_19) - 1 pcs. + Edge banding 1 x undefined (U999_19) - 0′ (0 m) Laminated Particle Board 0.39″x72.05″x108.27″ (10x1830x2750 mm) ( color H1180_37) - 1 pcs. + Edge banding 1 x 19 (H1180_37) - 2.37′ (7.78 m) Laminated Particle Board 0.63″x82.68″x110.24″ (16x2100x2800 mm) ( color FL-E078) - 1 pcs. + Edge banding 0.4 x 19 (U702_9) - 1.26′ (4.137 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E078) - 1 pcs. + Edge banding 0.4 x 19 (FL-E078) - 0.35′ (1.136 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color F187_9) - 1 pcs. + Edge banding 1 x 19 (F187_9) - 2.08′ (6.836 m)	Confirmats - 15 pcs. Hinge - 3 pcs. Shelf Holder - 26 pcs.

Materials

Hardware

Laminated Particle Board 0.63″x82.68″x110.24″ (16x2100x2800 mm) ( color W1000_9) - 1 pcs.
+ Edge banding 0.4 x 19 (W1000_9) - 3.64′ (11.95 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color W1000_9) - 1 pcs.
+ Edge banding 0.4 x 19 (W1000_9) - 1.58′ (5.174 m)

Lower Guide A08 0.24″x2.4″x106.3″ (6x61x2700 mm) ( color U999_19) - 1 pcs.
+ Edge banding 1 x undefined (U999_19) - 0′ (0 m)

Upper Guide A04 1.57″x3.23″x106.3″ (40x82x2700 mm) ( color U999_19) - 1 pcs.
+ Edge banding 1 x undefined (U999_19) - 0′ (0 m)

Laminated Particle Board 0.63″x82.68″x110.24″ (16x2100x2800 mm) ( color U702_9) - 2 pcs.
+ Edge banding 0.4 x 19 (U702_9) - 2.97′ (9.732 m)

Handle Profile A14 1.34″x1.02″x106.3″ (34x26x2700 mm) ( color U999_19) - 2 pcs.
+ Edge banding 1 x undefined (U999_19) - 0′ (0 m)

Top Profile A02 0.87″x0.59″x106.3″ (22x15x2700 mm) ( color U999_19) - 1 pcs.
+ Edge banding 1 x undefined (U999_19) - 0′ (0 m)

Bottom Profile A01 2.24″x0.59″x106.3″ (57x15x2700 mm) ( color U999_19) - 1 pcs.
+ Edge banding 1 x undefined (U999_19) - 0′ (0 m)

Laminated Particle Board 0.39″x72.05″x108.27″ (10x1830x2750 mm) ( color H1180_37) - 1 pcs.
+ Edge banding 1 x 19 (H1180_37) - 2.37′ (7.78 m)

Laminated Particle Board 0.63″x82.68″x110.24″ (16x2100x2800 mm) ( color FL-E078) - 1 pcs.
+ Edge banding 0.4 x 19 (U702_9) - 1.26′ (4.137 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E078) - 1 pcs.
+ Edge banding 0.4 x 19 (FL-E078) - 0.35′ (1.136 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color F187_9) - 1 pcs.
+ Edge banding 1 x 19 (F187_9) - 2.08′ (6.836 m)

Confirmats - 15 pcs.
Hinge - 3 pcs.
Shelf Holder - 26 pcs.
