Cuarto de fotos

Creator134658

0%

Cuarto de fotos Free 3D Furniture Projects and Blueprints from the Flatma Community

Interactive 3D model: rotate to inspect, open in designer to customize

This project is shared by the community and serves as a reference and starting point. Verify all dimensions and structural correctness before cutting

Open in Flatma

Cuarto de fotos amueblado

Overall material utilization factor - 41.15 %
Total edge banding length - 25.22′ (82.742 m)
Total cutting length - 51.89′ (170.243 m)

Materials	Hardware
Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1334_9) - 2 pcs. + Edge banding 1 x 19 (H1334_9) - 9.69′ (31.78 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1122_22) - 1 pcs. + Edge banding 1 x 19 (H1122_22) - 5.61′ (18.414 m) Particle Board 0.12″x66.93″x108.07″ (3x1700x2745 mm) ( color W1000_9) - 1 pcs. + Edge banding - 0′ (0 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E089) - 1 pcs. + Edge banding 1 x 19 (FL-E077) - 1.53′ (5.008 m) Lower Guide A08 0.24″x2.4″x106.3″ (6x61x2700 mm) ( color FL-E089) - 1 pcs. + Edge banding - 0′ (0 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E077) - 1 pcs. + Edge banding 1 x 19 (FL-E077) - 1.45′ (4.742 m) Стекло 0.2″x63.19″x100.39″ (5x1605x2550 mm) ( color Glass) - 1 pcs. + Edge banding - 0′ (0 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1146_10) - 1 pcs. + Edge banding 1 x 19 (H1146_10) - 4.34′ (14.23 m) Particle Board 0.12″x48.03″x108.07″ (3x1220x2745 mm) ( color W1000_9) - 1 pcs. + Edge banding - 0′ (0 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E088) - 1 pcs. + Edge banding 1 x 19 (FL-E078) - 2.61′ (8.568 m)	Confirmats - 40 pcs. Rafixes - 58 pcs.

Materials

Hardware

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1334_9) - 2 pcs.
+ Edge banding 1 x 19 (H1334_9) - 9.69′ (31.78 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1122_22) - 1 pcs.
+ Edge banding 1 x 19 (H1122_22) - 5.61′ (18.414 m)

Particle Board 0.12″x66.93″x108.07″ (3x1700x2745 mm) ( color W1000_9) - 1 pcs.
+ Edge banding - 0′ (0 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E089) - 1 pcs.
+ Edge banding 1 x 19 (FL-E077) - 1.53′ (5.008 m)

Lower Guide A08 0.24″x2.4″x106.3″ (6x61x2700 mm) ( color FL-E089) - 1 pcs.
+ Edge banding - 0′ (0 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E077) - 1 pcs.
+ Edge banding 1 x 19 (FL-E077) - 1.45′ (4.742 m)

Стекло 0.2″x63.19″x100.39″ (5x1605x2550 mm) ( color Glass) - 1 pcs.
+ Edge banding - 0′ (0 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1146_10) - 1 pcs.
+ Edge banding 1 x 19 (H1146_10) - 4.34′ (14.23 m)

Particle Board 0.12″x48.03″x108.07″ (3x1220x2745 mm) ( color W1000_9) - 1 pcs.
+ Edge banding - 0′ (0 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E088) - 1 pcs.
+ Edge banding 1 x 19 (FL-E078) - 2.61′ (8.568 m)

Confirmats - 40 pcs.
Rafixes - 58 pcs.
