Utility Table

Creator8083
0%
Utility Table Free 3D Furniture Projects and Blueprints from the Flatma Community
Table for use in a shop. Legs and back wall are angle iron while the table top could be made from a metal sheet or a slab of wood by adding some bolt holes in the table frame. I was having trouble ling up the table top with the frame because there were objects colliding but there is more angle iron along the front and side with the outside corner on the uppermost outside corner while the angle iron on the back is oriented with the outside corner on the low outside corner to prevent items from rolling and falling behind the table.
Overall material utilization factor - 24.99 %
Total edge banding length - 16.6′ (54.452 m)
Total cutting length - 23.13′ (75.886 m)
Materials Hardware
Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color W1000_9) - 1 pcs.
+ Edge banding 0.04 x 0.75 (W1000_9) - 16.6′ (54.452 m)

Hardware not specified
