Мой Free 3D Furniture Projects and Blueprints from the Flatma Community

Interactive 3D model: rotate to inspect, open in designer to customize

This project is shared by the community and serves as a reference and starting point. Verify all dimensions and structural correctness before cutting

Open in Flatma

Таня

Overall material utilization factor - 53.44 %
Total edge banding length - 37.65′ (123.535 m)
Total cutting length - 66.75′ (218.981 m)

Materials	Hardware
Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E086) - 3 pcs. + Edge banding 1 x 19 (U702_9) - 24.92′ (81.773 m) Laminated Particle Board 0.75″x72.05″x108.27″ (19x1830x2750 mm) ( color FL-E086) - 1 pcs. + Edge banding 1 x 21 (F187_9) - 6.43′ (21.098 m) Particle Board 0.12″x81.5″x110.24″ (3x2070x2800 mm) ( color FL-W103) - 1 pcs. + Edge banding - 0′ (0 m) Particle Board 0.12″x48.03″x96.06″ (3x1220x2440 mm) ( color FL-W103) - 2 pcs. + Edge banding - 0′ (0 m) Countertop 1.1″x23.62″x161.42″ (28x600x4100 mm) ( color FL-E080) - 1 pcs. + Edge banding - 0′ (0 m) Particle Board 0.12″x48.03″x96.06″ (3x1220x2440 mm) ( color FL-E086) - 1 pcs. + Edge banding - 0′ (0 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E082) - 1 pcs. + Edge banding 1 x 19 (U702_9) - 6.33′ (20.752 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E081) - 1 pcs. + Edge banding 1 x 19 (H1180_37) - -0.03′ (-0.088 m) Particle Board 0.12″x48.03″x96.06″ (3x1220x2440 mm) ( color FL-E082) - 1 pcs. + Edge banding - 0′ (0 m)	Confirmats - 140 pcs. Hinge - 6 pcs.

Materials

Hardware

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E086) - 3 pcs.
+ Edge banding 1 x 19 (U702_9) - 24.92′ (81.773 m)

Laminated Particle Board 0.75″x72.05″x108.27″ (19x1830x2750 mm) ( color FL-E086) - 1 pcs.
+ Edge banding 1 x 21 (F187_9) - 6.43′ (21.098 m)

Particle Board 0.12″x81.5″x110.24″ (3x2070x2800 mm) ( color FL-W103) - 1 pcs.
+ Edge banding - 0′ (0 m)

Particle Board 0.12″x48.03″x96.06″ (3x1220x2440 mm) ( color FL-W103) - 2 pcs.
+ Edge banding - 0′ (0 m)

Countertop 1.1″x23.62″x161.42″ (28x600x4100 mm) ( color FL-E080) - 1 pcs.
+ Edge banding - 0′ (0 m)

Particle Board 0.12″x48.03″x96.06″ (3x1220x2440 mm) ( color FL-E086) - 1 pcs.
+ Edge banding - 0′ (0 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E082) - 1 pcs.
+ Edge banding 1 x 19 (U702_9) - 6.33′ (20.752 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color FL-E081) - 1 pcs.
+ Edge banding 1 x 19 (H1180_37) - -0.03′ (-0.088 m)

Particle Board 0.12″x48.03″x96.06″ (3x1220x2440 mm) ( color FL-E082) - 1 pcs.
+ Edge banding - 0′ (0 m)

Confirmats - 140 pcs.
Hinge - 6 pcs.
