Caixa de instrumentos

Creator96622

0%

Caixa de instrumentos Free 3D Furniture Projects and Blueprints from the Flatma Community

Interactive 3D model: rotate to inspect, open in designer to customize

This project is shared by the community and serves as a reference and starting point. Verify all dimensions and structural correctness before cutting

Open in Flatma

caixao para guardar instrumentos

Overall material utilization factor - 31.26 %
Total edge banding length - 13.41′ (44 m)
Total cutting length - 34.38′ (112.808 m)

Materials	Hardware
Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color W1000_9) - 2 pcs. + Edge banding 1 x 19 (W1000_9) - 6.61′ (21.682 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1123_22) - 1 pcs. + Edge banding 1 x 19 (W1000_9) - 2.49′ (8.176 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1180_37) - 1 pcs. + Edge banding 1 x 19 (W1000_9) - 3.07′ (10.076 m) Particle Board 0.12″x66.93″x108.07″ (3x1700x2745 mm) ( color W1000_9) - 1 pcs. + Edge banding - 0′ (0 m) Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1145_10) - 1 pcs. + Edge banding 1 x 19 (W1000_9) - 1.24′ (4.066 m)	Hardware not specified

Materials

Hardware

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color W1000_9) - 2 pcs.
+ Edge banding 1 x 19 (W1000_9) - 6.61′ (21.682 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1123_22) - 1 pcs.
+ Edge banding 1 x 19 (W1000_9) - 2.49′ (8.176 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1180_37) - 1 pcs.
+ Edge banding 1 x 19 (W1000_9) - 3.07′ (10.076 m)

Particle Board 0.12″x66.93″x108.07″ (3x1700x2745 mm) ( color W1000_9) - 1 pcs.
+ Edge banding - 0′ (0 m)

Laminated Particle Board 0.63″x72.05″x108.27″ (16x1830x2750 mm) ( color H1145_10) - 1 pcs.
+ Edge banding 1 x 19 (W1000_9) - 1.24′ (4.066 m)

Hardware not specified
